Roof penetration coring is the process of cutting clean round holes through a concrete roof slab so pipes, drains, conduits, exhausts or plant supports can pass through. On a concrete roof in Victoria, doing it properly means four things in order: scan the slab for hidden services and reinforcement, get the paperwork and dust controls in place, core with a wet or dust-captured diamond drill, then hand the hole to the waterproofer so it is flashed as part of a complete system. Skip any of the four and you risk a damaged cable, a safety breach or a leak that shows up months later.

This guide is for contractors, property managers, engineers and building owners who need to plan penetrations in an existing concrete roof or podium deck.

TL;DR

• Scan before you core. Post-tensioning cables, conduits and rebar can sit anywhere in a roof slab, and a scan is the cheapest insurance on the job.
• In Australia, penetration or coring work 50 mm deep or more is treated as high-risk construction work on many managed sites, with a permit, risk assessment and SWMS.
• Cutting concrete creates respirable crystalline silica. Use water suppression or on-tool extraction, and clear the area.
• The core is only half the job. The penetration needs purpose-made flashing and a waterproofing system that integrates with the roof membrane.
• Plan the hole count, sizes and positions with the roofer before the drill arrives.

Table of Contents

• What roof penetration coring involves
• Why the hole is the easy part
• Step 1: Scan the slab
• Step 2: Permits, risk assessment and SWMS
• Step 3: Control silica dust and slurry
• Step 4: Core the holes
• Step 5: Restore structure and flash the penetration
• Planning checklist for contractors and property managers
• Common mistakes on roof coring jobs
• Our perspective
• Cost and what affects it
• Book roof coring in Melbourne
• FAQ
• Sources

What roof penetration coring involves

A roof penetration is any object or opening that passes through the roof surface. On a concrete roof, the opening is usually made with a core drill: a rig fitted with a hollow, diamond-tipped bit that cuts a cylinder out of the slab. The result is a round, smooth-walled hole that can be sized to suit the service going through it.

Typical reasons to core a roof slab:

• Roof drains and overflow outlets
• Mechanical exhaust, kitchen exhaust and ventilation risers
• Plumbing vents and stack penetrations
• Electrical and data conduits feeding rooftop plant
• Refrigerant lines for air conditioning condensers
• Posts for guard rails, anchors and fall-arrest systems
• Solar array cable entries

Coring is preferred over breaking out a hole with a jackhammer because it is accurate, causes little vibration and leaves a neat edge. That matters on an occupied building, where noise and shock travel down through the structure. If you want a primer on the process itself, our page on what core drilling is covers the basics.

Why the hole is the easy part

The drilling itself takes minutes per hole in most slabs. What goes wrong on roofs is almost never the core. It is what happens before and after.

The National Construction Code requires a roof to prevent water getting into the building, and the weatherproofing provisions cover openings. Industry guidance reflected in the code’s performance requirements, along with NCC Part H2 on damp and weatherproofing, makes clear that every opening is a place where moisture can enter. Roof penetrations are widely regarded as one of the most common leak points on any roof, which is why designers try to reduce their number in the first place.

Two practical conclusions follow:

1. Fewer, better-placed holes. Group services together where you can, and use a structural platform rather than many individual fixings. Facilities guidance from Australian National University says roof-mounted equipment should sit on a structurally sound platform designed with a limited number of roof penetrations.
2. A coordinated sequence. The coring contractor and the roofer need to agree hole positions, diameters and timing before anyone starts.

Step 1: Scan the slab

Before a bit touches the roof, you need to know what is inside it. Concrete roof slabs commonly contain reinforcing bar, electrical conduit, drainage falls cast into the topping and, in some buildings, post-tensioned cables. Hitting a tensioned cable is dangerous and expensive. Hitting rebar will stall the bit and may weaken the slab if cut without engineering approval.

The ANU facilities standard is blunt on this point: it calls for service scans before starting work to avoid hitting hidden conduits, rebar or post-tensioning cables. Our concrete scanning service uses ground-penetrating methods to map what is inside the slab, so holes can be moved a few centimetres to clear a cable instead of being abandoned or, worse, drilled blind.

What a good scan result gives you:

• Marked positions of reinforcement and conduits on the slab surface
• An approximate slab thickness, so you know how deep the core must go
• A clear go or no-go for each proposed location
• A record you can hand to the engineer

If the scan shows a hole location conflicts with structural steel or tendons, the engineer decides what happens next. That decision is not one for the drilling crew to make on the day.

Step 2: Permits, risk assessment and SWMS

In Australia, the requirement depends on the site and the building owner’s rules, but a widely used standard is clear. According to Baseline’s published coring standard, any penetration, coring or cutting that goes 50 mm or deeper into a structure such as a slab or wall is high-risk construction work. That standard requires a permit, a project risk assessment and an approved Safe Work Method Statement, submitted to the site representative at least 7 days before work starts.

Most roof slabs are well over 50 mm thick, so assume this applies. Even where a particular building does not use that exact standard, major managed buildings, hospitals, universities and shopping centres have similar rules.

What this means for your programme:

• Allow at least a week between engaging a coring contractor and starting, longer on a managed site.
• Make sure the SWMS names the specific hazards of a roof: edges, falls, services below, dust and slurry.
• Confirm who is on site for the permit. On a tenanted building, that may be the facilities manager rather than the owner.

We prepare job-specific documentation and run to your site’s induction and permit system. If you are early in planning, tell us when you send the enquiry so we can build the lead time into the schedule.

Step 3: Control silica dust and slurry

Concrete contains crystalline silica. Drilling it releases respirable crystalline silica (RCS), a serious long-term health hazard. Safe Work Australia’s model code of practice on managing the risks of respirable crystalline silica lists using power tools or mechanical plant for drilling or cutting a crystalline silica substance as a process that needs risk management.

The hierarchy of control matters. The Safe Work Australia silica guidance lists isolating the hazard, for example designating areas for dust-generating tasks, and engineering controls that minimise dust exposure. For rooftop work specifically, Safe Work Australia’s guide to rooftop solar installation says respiratory protection is only acceptable where engineering controls such as on-tool extraction or water suppression are not reasonably practicable. Respirators are the last line, not the plan.

In practice on a roof:

• Wet coring keeps dust down at the bit. The trade-off is slurry, which must be contained, vacuumed and kept out of drains and off membranes.
• Dust capture systems pull dust at the source when water cannot be used, for example above sensitive equipment or in occupied floors below.
• Exclusion zones keep other trades and the public clear while work is under way.

We compare the two approaches in wet versus dry cutting and explain how extraction works in our guide to dustless concrete cutting in Melbourne.

On a roof, slurry control has a second purpose beyond health. Wet slurry running across a membrane or into a roof drain stains finishes, blocks outlets and can contaminate the surface that the waterproofer needs clean and dry for adhesion.

Step 4: Core the holes

With scanning done, permits approved and controls in place, the coring itself follows a routine sequence.

1. Mark out each hole from the scan, checking diameter against the service and flashing to be fitted. Allow clearance around the pipe for the flashing and any sleeve.
2. Fix the rig. On a roof the rig is usually anchored to the slab or held by vacuum base so it cannot walk. A stable rig gives a straight, true hole.
3. Select the bit. Diamond segments are matched to the aggregate and the amount of steel expected.
4. Start the core with light pressure and water supply on, then let the bit do the cutting.
5. Remove the core plug. On a roof, ensure the plug cannot fall through to the floor below once the cut is complete. Plugs are supported or secured, and the area below is cleared.
6. Clean the hole. Vacuum slurry, remove loose material and leave the edge ready for the next trade.

Core depth and time depend on slab thickness and reinforcement. If you want to understand limits, see how deep you can core drill concrete and how long core drilling takes. For most roof penetrations, the drilling is a fraction of the total time spent setting up and cleaning up.

Tight access and rooftop logistics

Roofs are rarely easy places to work. Water supply, power, hoisting equipment and access through hatches can all shape the job. Plant rooms and parapet edges limit where a rig can sit. Our notes on concrete drilling in tight spaces cover how we approach cramped locations. Tell us early about hatch sizes, lift access and whether a crane is available, because it changes the equipment we bring.

Step 5: Restore structure and flash the penetration

Once the core is out, two questions remain: is the structure still sound, and will the hole stay watertight?

Structural restoration

Any opening can weaken the element it passes through. The ANU roofing standard says that after coring or cutting, the structure must be restored to its original strength, with roof trimmers or soaker supports where needed. Large openings, or several holes close together, should be reviewed by the structural engineer before coring, not after. Cutting through reinforcement without sign-off is where problems begin.

Flashing and waterproofing

The NCC treats weatherproofing as a performance requirement, and the research behind the code’s provisions points to systems rather than patches. According to the NCC H2 weatherproofing part, flashing for penetrations should be purpose-made, with at least a 75 mm upturn and enough width around the penetration, and it must allow total drainage of the area above. For concrete roofs over internal spaces, materials and installation should align with AS 4654.1 and AS 4654.2.

The practical points a waterproofer will work to:

• Use a complete, compatible system: primer, membrane, flashing and sealant that suit each other and the substrate.
• Avoid caulking as the only defence. A bead of sealant around a pipe is a maintenance item, not a waterproofing system.
• Watch dissimilar metals. CSIRO’s APAS certification document covers damp-proof course and flashing materials, and corrosion between incompatible metals is a recognised failure point.
• Clear all metal swarf and debris from the roof straight away. The ANU standard notes that fillings and rivets left on the roof can corrode sheet material.

We do not apply membranes. Our role is to give the waterproofer a round, clean, correctly sized, correctly positioned hole, ideally with the sizes and tolerances they asked for.

Planning checklist for contractors and property managers

Use this list when you brief a coring contractor and your roofer together.

One more point on warranty: some roof membrane warranties are voided if unapproved trades penetrate the roof. Ask the roofer or membrane supplier what they require before you book the coring.

Common mistakes on roof coring jobs

• Coring first, asking later. A hole in the wrong place cannot be uncored. Fixing it means patching a structural slab.
• Holes too close to parapets, drains or each other. Flashing needs room to be detailed correctly.
• No plan for the core plug. Heavy plugs can drop through to the space below if not secured.
• Using roof space as an afterthought for plant. The ANU standard recommends against using roofs as plant areas; where unavoidable, a designed platform keeps penetrations to a minimum.
• Sealing with caulk alone. It looks finished on handover day and fails a season later.

Our perspective

We core roof slabs across Melbourne and Victoria, and the jobs that go smoothly share one trait: the people involved spoke to each other before the rig arrived. The coring contractor, roofer and engineer each hold a piece of the answer. We cannot tell you the right flashing detail, and the roofer cannot tell you what is inside your slab.

Our approach is to scan first, work to your site’s permit and SWMS process, use wet cutting or dust capture as the job requires, and leave a clean, accurately sized hole. We would rather move a core 100 mm after a scan than explain a severed conduit. If a requested location looks wrong to us, we say so before we start.

We also encourage clients to count their holes. If three small penetrations can be combined into one larger, well-flashed opening, the roof usually benefits.

— MYBMC

Cost and what affects it

We publish a range for concrete cutting of $450 to $5,000 per job, which reflects the spread between a few small holes and a larger, more complex scope. We do not publish a fixed price for roof coring, because the number depends on the factors that actually change the work:

• Slab thickness and bit diameter
• Quantity of holes
• Reinforcement density
• Access: stairs, hoisting or a crane
• Scanning requirements
• Dust and slurry controls, and out-of-hours work

The simplest way to get a firm figure is to send the number and size of holes, the slab type and any site rules, and we will quote against that.

Book roof coring in Melbourne

If you have a concrete roof or podium that needs penetrations, we can scan, core and leave the holes ready for your waterproofer. Our operators are licensed and qualified, and we work to OH&S safety standards on small domestic jobs and large construction projects alike. See our core drilling service or request a free quote with your hole schedule and site details. If you are working in the inner suburbs, our Richmond concrete cutting page has local details, and our Melbourne concrete cutting page covers larger projects.

FAQ

Can I core a hole in a concrete roof myself?

It is not advisable. You need to scan for cables and reinforcement, manage silica dust, and often hold a permit and SWMS. The hole must also be positioned and sized to suit the waterproofing. Hire a licensed operator and coordinate with your roofer.

Who is responsible for waterproofing after coring?

The roofer or waterproofing contractor, not the coring contractor. The coring crew provides a clean, correctly sized hole. The waterproofer then installs flashing and membrane as a complete system, in line with the NCC weatherproofing provisions and the relevant Australian Standards.

How deep is a typical roof core?

It matches the slab thickness, which varies by building and roof type. Many sites treat any penetration of 50 mm or more as high-risk work needing a permit and SWMS. A scan gives the real thickness before the job. See our guide on how deep you can core drill concrete.

Is wet or dry coring better on a roof?

Wet coring is the usual first choice because water suppresses silica dust at the source, but slurry must be contained. Where water is a risk, such as above sensitive equipment, dust capture with extraction is the alternative. Respirators alone are only acceptable where engineering controls are not reasonably practicable.

Sources

• Penetration, Coring & Concrete Cutting | Baseline
• Part H2 Damp and weatherproofing | WaterMark (NCC 2025)
• 05 – Roofing, Roof Fabric & Roof Safety | ANU
• Managing risks of respirable crystalline silica in the workplace | Safe Work Australia
• Silica | Safe Work Australia
• Guide to managing the risks of rooftop solar installation work | Safe Work Australia
• Product certification system, damp proof courses and flashing | CSIRO APAS
